TR-D8121CL2 4.0
Technical specifications
PoE:
69Audio:
Built-in microphoneWDR:
RWDR 120 dBFrame rate:
25Electronic shutter speed:
1/2 ~ 1/1 000 sDigital noise Reduction:
3D DNRCorridor mode:
YesBitrate (Mb/sec):
8Archive, Tb:
151Power supply:
12V DCOverview
2 MP (1920×1080) IP camera TRASSIR TR-D8121CL2 (2.8 mm) is based on a highly sensitive (0.0015 lx) 1/2.8" matrix, equipped with a fast (F/1.0) lens and LED-backlight with a range of 25 m, due to which broadcasts color video around the clock.Designed taking into account the conditions of outdoor operation, regardless of the season: protection of the case against dust and moisture complies with the IP66 standard, operating temperatures from -40 °C ... +60 °C, lightning protection - TVS 4000 V.
Functionality
Basics
H.264, H.264+, H.265 and H.265+ codecs are provided for compression, RJ-45 connector for network connection. The focal length of the lens is 2.8 mm, the horizontal viewing angle is 105°, and the vertical is 54°. Power supply - DC 12 V, PoE. Power: DC - 3.50 W, PoE - 3.36 W max. Size - Ø93.0×92.2 mm, weight - 400 g.
Functionality
- Built-in microphone.
- Detection of people, movement, virtual line crossing, area entry, area exit, area crossing.
-
WDR 120 dB - minimizes the effect of changes in illumination levels on picture quality: 2-fold scanning with different exposures and further formation of the final balanced frame.
- 3D DNR - spatial noise reduction.
- BLC - backlight correction.
- Defog - Eliminates blur caused by fog or smoke in the scene.
- Broadcast speed - 25 fps. Bitrate - 8 Mbps.
Basics
H.264, H.264+, H.265 and H.265+ codecs are provided for compression, RJ-45 connector for network connection. The focal length of the lens is 2.8 mm, the horizontal viewing angle is 105°, and the vertical is 54°. Power supply - DC 12 V, PoE. Power: DC - 3.50 W, PoE - 3.36 W max. Size - Ø93.0×92.2 mm, weight - 400 g.
Documentation
TR-D8121CL2_passport_en.pdf
