TR-H2S6 2.8-12

TRASSIR TR-H2S6

Analog indoor 2 MP (1920 × 1080) camera compatible with AHD, HD-CVI, HD-TVI data transfer formats: transmits an uncompressed 2 MP video signal over a distance of up to 500 m (1,000 ft). Designed year-round or daytime outdoor use: the enclosure is protected against dust and moisture in accordance with the IP67 norm, operating temperatures: -30 °C to +60 °C.

Resolution by format:

• AHD — 2 MP.

• HD-CVI — 2 MP.

• HD-TVI — 2 MP.

• PAL — 960H.

Functionality:

• DWDR is a software-based image processing that selectively brightens shaded objects.

• 2D DNR: Noise reduction.

• Day/night mode with an ICR filter: in conditions where light is sufficient, the ICR refracts the IR rays, standardizing color rendition; in low light, it mechanically shifts to optimize the matrix sensitivity to the infrared range and the operation of the backlight function.

• Broadcast speed: 25 frames per second.

• IR with a range of 30 m.

Basic specifications:

TR-H2S6 is built on a 1/3" progressive scan CMOS sensor with 0.01 lux sensitivity. Equipped with a 2.8 ~ 12 mm zoom lens, horizontal field of view of 97° ~ 37°, vertical field of view of 60° ~ 22°. Supplied with swing bracket for easy installation Power supply: 12 V DC Current consumption: 550 mA Power: 6.6 W. Size: Ø119 × 98 mm Weight: 800 g.
