TR-Lite L2B5 2.8

Technical specifications

PoE:

69

WDR:

DWDR 105 dB

Bitrate (Mb/sec):

up to 8Mbps

Archive, Tb:

151

Power supply:

PoE (802.3af) / 12V DC
Overview

The 2 MP (1920×1080) IP camera TRASSIR TR-Lite L2B5 2.8 is supplied in a metal housing, protected from moisture and dust according to IP67 standards. Along with operating temperatures ranging from -30°C to +60°C and TVS 4000 V surge protection, this ensures stable device operation outdoors throughout the year. TR-Lite cameras, together with TR-Lite video recorders, form an autonomous system that allows remote monitoring via cloud and mobile application. Working with TRASSIR software under the TRASSIR license is not supported.


Functionality:

· DWDR: Image processing for low-light conditions.

· 3D DNR: Spatial noise reduction.

· Day/Night mode with mechanical filter: Refracts infrared radiation in sufficient light.

· The camera is equipped with a strobe - rapid flashing of the illumination, activated upon event detection.

· 1/2.9" CMOS sensor with a sensitivity of 0.005 lux.

· Fixed-focus lens with a focal length of 2.8 mm, providing horizontal and vertical viewing angles of 98° and 53°, respectively, with an aperture of F/1.8.


Basics:

· Codecs for compression include H.265, H.264, MJPEG. For night surveillance, there's IR illumination with a range of 30 meters.

· Power supply options: DC 12 V, PoE. Maximum power consumption is 3.5 W. Dimensions are 152.1×68.3×62.9 mm, and it weighs 390 g.
