TR-D3351WDIR4

Overview:

The 5 MP (2592x1920) IP camera TR-D3351WDIR4 2.8 / 3.6 is adapted for year-round outdoor use in areas with direct access. The housing is protected against moisture and dust according to the IP67 standard, and against mechanical impacts according to the IK10 standard. It operates in temperatures ranging from -40°C to +60°C and features surge protection rated at TVS 4000V.

Functionality:

· Detection of motion, faces, people, line crossing, area entrance and exit, loitering, vehicles, and people counting.

· IR illumination range of 40 meters.

· WDR 120 dB — eliminates the impact of varying light levels on image quality.

· 3D DNR — suppression of spatial noise.

· Defog — software removal of blur caused by fog or smoke.

· BLC — backlight compensation.

· HLC — masking of local light sources.

· Day/Night mode with ICR: in sufficient light, the filter blocks IR rays to optimize color rendering, and in darkness, it mechanically moves away from the sensor to increase sensitivity.

· Compression: H.265+, H.265, H.264.

· Streaming speed: 25 fps with WDR off, 25 fps with WDR on. Bitrate: 8 Mbps.

· Built-in microphone.

· Cold start.

Basics:

The TR-D3351WDIR4 2.8/3.6 is built on a 1/2.7" CMOS sensor with a sensitivity of 0.003 lux. It is equipped with a fixed focal length lens of 2.8mm with a horizontal viewing angle of 99° and a vertical viewing angle of 72°; and a 3.6mm lens with a horizontal viewing angle of 79° and a vertical viewing angle of 60°. The aperture is F/1.3. The camera features an RJ-45 network port, audio input, audio output, alarm input, alarm output, and a microSD slot with a capacity of up to 256 GB. It is powered by 12V DC or PoE with a maximum power consumption of 5.6W. The dimensions are Ø116.10×96.51 mm, and it weighs 520 g.
